Functions |
- Supports AP , AP Client , Bridge , WDS and Universal Repeater mode
- Port Triggering for Special Applications
- DDNS (DynDNS, TZO)
- Virtual Server and DMZ
- Access Control List and URL Blocking
- Static Routing
- UPnP
- VPN Pass Through (IPSec/PPTP)
- Supports Windows OS (98SE/ME/NT/2000/2003/XP/Vista), Mac OS X and Linux
|
Hardware Interface |
- 1 WAN + 4 LAN 10/100/1000Mbps Ethernet Ports
- LED Indicators: Power, WAN, LAN and LNK/ACT
- 3dBi RP-SMA Detachable Antenna x 3
- WPS / Reset Button
|
Management & Installation |
- Supports Remote Management
- Supports EZView Management
- System Status and Security Log (Web Interface)
- Firmware Upgradeable
- Multi-language EZmax Setup Wizard
|
WAN |
- Supports cable/xDSL modem
- WAN protocol: PPPoE, Static IP, PPTP, Dynamic IP, L2TP2
|
Output Power |
- 11n: 16±1dBm,
- 11g: 16±1dBm,
- 11b: 18±1dBm
|
Receive Sensitivity |
- 11n (40MHz): -68dBm,
- 11n (20MHz): -71dBm,
- 11g: -74dBm,
- 11b: -87dBm
|
Security |
- NAT/NAPT IP sharing
- 64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security
- DHCP Server/Client
- QoS
- SPI Anti-DoS Firewall
|
Memory |
|
Humidity & Temperature |
- Humidity: 10-90% (non-condensing)
- Temperature: 0-45°C
|
Power Adapter |
|
Dimensions |
- 192 (W) x 115 (D) x 29 (H) mm
|
Certification |
|
